AlphaScan 1D
School Cafeteria Pin Pad with 1D Barcode Scanner
Our school lunch keypad with 1D barcode reader AphaScan 1D is specifically designed to allow school students to scan their one-dimensional ID barcode fast and easy.
Make School Lunch Lines Move Faster With AlphaScan 1D Barcode Scanner!
What Are 1D Barcodes?
1D barcodes are linear codes including alphanumeric data.
AlphaScan 1D Specifications
Features
- Compatible with all school nutrition software.
- Fully programmable.
- CCD Barcode Scanner built in the front of the Pin Pad.
- Super fast response rate.
- Scan all standard student ID cards featuring barcodes.
- Audible beep with adjustable volume and pitch.
- Programmable modern blue LCD display (2×16).
- Tactile embossed keys with Braille.
- Masking / unmasking controls.
- USB HID and virtual serial Com port.
- Standard 6 foot USB cable.
Benefits
- Faster student check-in makes lunch line moves faster.
- Easy to operate for cafeteria attendants.
- Easy to operate for students.
- Touchless.
- Reads 1D barcodes off phones
- Accurate tracking of meal activity.
- Safe: unlike Laser Scanners our CCD Barcode Scanner will not damage the eyes if looked at the scanner directly.
- Small Footprint.
- Ability to run two lines at once.
- Complementary anti-shock rubber cover.
- Try before you buy with our 30-day money back guaranty.
- 1 to 3 year warranty.
Product Information
- Number of Keys: 14 Keys (3×5)
- USB Interface: USB 2.0 / 1.1 Full Speed
- Power Supply: 5v DC, 110mA (max), USB Bus Powered
- LCD Type: 2 Line x 16 Character STN LCD Display
- 1D: Codaba, Code11, Code128, ISBT128, Code32, Code39, TLC39, Code93/93i, BC412, UK Plessey, Anker Plessey, EAN-13, EAN-8, GS1, MSI, Telepen, Pharma, PatchCode, UPC-A, UPC-E.
Product Information
- Dimensions: 6.75 x 3.75 x 1.375 in.
- Weight: 9 oz / 13 oz with protective cover.
- Operating Temperature: 32 to 140 °F
- Operating Humidity: 5% to 90% Non-Condensing.
- FCC Rating: Class B Device.
Accessories
Protective Covers
Our unique anti-shock protective covers offer extra rugged protection for your barcode scanners.
Pin Pad Stands
Our stand solutions designed to be paired with our school cafeteria barcode readers.
USB Cables
Our USB cables are certified and compatible with all our school cafeteria keypads.
Our Pledge to Quality
Warranty
Our Pin Pads are covered by a standard 1-year warranty + up to 3 year optional extended warranty available upon request.
FCC Approved
Our cafeteria keypad components are FCC approved.
US Company
Our keypads are designed, assembled in the US, ship from our warehouse in Irvine, California.
